General Specifications
NoteCITATION MULTIBEAM 700 is in compliance with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013.
Power consumption:-Yes
Off ModeN/A
StandbyN/A
Network Standby*2.0 Watts
Time to networked standby18 minutes *
Networked standbyin the condition of any wireless connection of the device is activated, if no provide any audio or video signal to the device, it will automatically into networked standby mode in 18 minutes. Any audio or video recover will bring device from standby to operation mode.
Audio Specifications
Transducer2 x 25mm tweeter, 5 x 50mm woofer
Output power210W RMS
Signal-to-noise ratio>80dB
Dimensions
Dimensions (W x H x D)790 x 65 x 130mm (31.1" x 2.6" x 5.1")
Weight: 3.7kg (8.1lb)Yes
Control and Connection Specifications
Bluetooth® version4.3
Bluetooth transmitter frequency range2402 – 2480MHz
Bluetooth transmitter power<10dBm
Bluetooth transmitter modulationGFSK,π/4 DQPSK, 8DPSK
Wireless network802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range2412 – 2472MHz (2.4GHzISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power<20dBm
2.4G Wi-Fi modulationDBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G Wi-Fi transmitter power<23dBm
5G Wi-Fi modulationQPSK, BPSK, 16QAM, 64QAM, 256QAM
5G Wi-Fi transmitter frequency range5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
Battery
Power Supply100-240V~50/60Hz
Power consumption in sleep mode<2.0 Watts
Notification
Google, Google Play, Chromecast, Chromecast built-in, Google Home and other related marks and logos are trademarks of Google Inc.Yes
Chromecast built-in may require subscription(s).-
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners. The Wi-Fi CERTIFIED Logo is certification marks of the Wi-Fi Alliance.-
* Requires compatible device. Availability and performance of certain other features and services are service, device and network-dependent and may not be available in all areas; subscription(s) may be required, and additional terms, conditions and/or charges may apply.-
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. -
The terms HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States.-
Features, specifications and appearance are subject to change without notice.-
