Capacity (Cooling, Btu/hr)
11533 Btu/hr
Capacity (Cooling, kW)
3.38 kW
EER (Cooling, W/W)
3.12 W/W
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
732×555×330 mm
Capacity (Cooling, Btu/hr)
11533 Btu/hr
Capacity (Cooling, Min - Max, Btu/hr)
3,071-13,648 Btu/hr
Capacity (Cooling, kW)
3.38 kW
Capacity (Cooling, Min - Max, kW)
0.90-4.00 kW
EER (Cooling, W/W)
3.12 W/W
EER (Cooling, Btu/hW)
10.65 Btu/hW
Noise Level (Indoor, High/Low, dBA)
38/28 dBA
Noise Level (Outdoor, High/Low, dBA)
50 dBA
Power Source(Φ/V/Hz)
1 / 220-240 / 50
Power Consumption(Cooling, W)
1083 W
Operating Current(Cooling, A)
5.0 A
Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)
921×281×379 mm
Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
794×615×376 mm
Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)
845×289×209 mm
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
732×555×330 mm
Gross Weight (Indoor, kg)
13.0 kg
Gross Weight (Outdoor, kg)
28.0 kg
Net Weight (Indoor, kg)
10.5 kg
Net Weight (Outdoor, kg)
23.5 kg
Loading Quantity (20/40/40Hft with Pipe)
97/206/241
Piping Length (Max, m)
20 m
Piping Height (Max, m)
10 m
SVC Valve (Liquid (ODxL))
φ6
SVC Valve (Gas (ODxL))
φ9.52
Moisture Removal (l/hr)
1.40 l/hr
Air Circulation (Cooling, ㎥/min)
680 ㎥/min
Refrigerant (Type)
R410A
Refrigerant (Charging, kg)
0.55 kg
Low Ambient (Cooling, ℃)
18~48 ℃
Air Direction Control (Up/Down)
Auto
Air Direction Control (Left/Right)
Manual
Air Flow Control Step (Cool/Fan)
3 Step
Auto Clean (Self Cleaning)
No
Filter Cleaning Indicatior
No
Indoor Temp. Display
Yes
Display On/Off
Yes
Beep On/Off
No
24-Hour Timer
Yes
Auto Changeover
No
Auto Restart
Yes
Fast Cool
Yes
Good Sleep
Yes
Dehumidification
Yes
Fan Mode
Yes
Quiet
No
