Capacity (Cooling, Btu/hr)
18016 Btu/hr
Capacity (Cooling, kW)
5.28 kW
EER (Cooling, W/W)
2.82 W/W
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
790*548*285 mm
Capacity (Cooling, Btu/hr)
18016 Btu/hr
Capacity (Cooling, Min - Max, Btu/hr)
6,654 ~ 20,473 Btu/hr
Capacity (Cooling, kW)
5.28 kW
Capacity (Cooling, Min - Max, kW)
1.95 ~ 6.0 kW
EER (Cooling, W/W)
2.82 W/W
EER (Cooling, Btu/hW)
9.61 Btu/hW
Noise Level (Indoor, High/Low, dBA)
43 / 26 dBA
Noise Level (Outdoor, High/Low, dBA)
51 dBA
Power Source(Φ/V/Hz)
1 / 220-240~ / 50
Power Consumption(Cooling, W)
1875 W
Operating Current(Cooling, A)
8.5 A
Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)
950*290*375 mm
Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
913*622*371 mm
Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)
889*299*215 mm
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
790*548*285 mm
Gross Weight (Indoor, kg)
11.6 kg
Gross Weight (Outdoor, kg)
35.4 kg
Net Weight (Indoor, kg)
10.1 kg
Net Weight (Outdoor, kg)
32.4 kg
Loading Quantity (20/40/40Hft without Pipe)
85 / 180 / 208
Loading Quantity (20/40/40Hft with Pipe)
85 / 178 / 204 (ACCE 60)82 / 175 / 197 (ACCE 80)
Piping Length (Max, m)
20 m
Piping Height (Max, m)
12 m
SVC Valve (Liquid (ODxL))
6.35
SVC Valve (Gas (ODxL))
12.7
Moisture Removal (l/hr)
2.0 l/hr
Air Circulation (Cooling, ㎥/min)
13.7 ㎥/min
Refrigerant (Type)
R410A
Refrigerant (Charging, kg)
1.05 kg
Refrigerant (Charging, tCO2e)
2.19 tCO2e
Low Ambient (Cooling, ℃)
16~46 ℃
Outdoor Unit (Compressor Type)
BLDC
Outdoor Unit (Anti-Corrosion Fin)
Yes
Air Direction Control (Up/Down)
Auto
Air Direction Control (Left/Right)
Auto
Air Flow Control Step (Cool/Fan)
5/4
Auto Clean (Self Cleaning)
Yes
Filter Cleaning Indicatior
Yes
Indoor Temp. Display
Yes
Display On/Off
Yes
Beep On/Off
Yes
24-Hour Timer
Yes
Auto Changeover
No
Auto Restart
Yes
Fast Cool
Yes
Good Sleep
Yes
Dehumidification
Yes
Fan Mode
Yes
Quiet
Yes
