Rated Heating Performance - COP (W/W)3.06
Rated Cooling Performance - Capacity (W)2635(600~2800)
Rated Cooling Performance - EER (W/W)2.92
Rated Cooling Performance - Max current (A)9.0
Rated Heating Performance - Rated current (A)3.9(1.4~9.0)
RefrigerantR410A / 0.48kg
Indoor noise level (dB(A))41
Indoor air flow (Hi) (m3/h)450
Power supply (Ph-V-Hz)1Ph-220-240V~50Hz
Indoor unit - Net/Gross weight (Kg)6.5 / 8.5
Outdoor unit - Packing(W*D*H) (mm)765×310×481
Refrigerant piping - Max. refrigerant pipe length (m)15
Outdoor unit - Net/Gross weight (Kg)20 / 24
Ambient temperature (℃)-15~50
Pressure - High(DP) (MPa)4.5
Connecting Wiring (Size x Core number)1.0mm² X 4
Refrigerant piping - Liquid side/ Gas side (mm(inch))φ6(7/16")/φ9.52(5/8")
Outdoor unit - Dimension(W*D*H) (mm)660×230x456
Rated Heating Performance - Max power Input (W)1200
Voltage Range (V)155~265
Compressor (Model)35W2ALLB9F#MC
Rated Cooling Performance - Max power Input (W)1300
Qty 40'HQ355
Moisture removal (Liters/h)1.0
Compressor (Type)Rotary
Indoor unit - Dimension(W*D*H) (mm)698×190×255
Rated Cooling Performance - Rated current (A)4.1(1.4~9.0)
Pressure - Low(SP) (MPa)1.9
Control typeRemote
Rated Heating Performance - Capacity (W)2635(600~2900)
Outdoor noise level (dB(A))52
Rated Cooling Performance - Capacity (Btu/h)9000(2050~9550)
TypeCooling and Heating, Inverter
Rated Heating Performance - Max current (A)9.0
Indoor unit - Packing(W*D*H) (mm)764×325×257
Refrigerant piping - Max. difference in level (m)10
Suitable area (m²)9~16
Rated Heating Performance - Capacity (Btu/h)9000(2050~9900)
Rated Heating Performance - Rated power Input (W)860(300~1200)
Compressor (Brand)Rechi
Rated Cooling Performance - Rated power Input (W)900(300~1300)
